Model |
SL500 |
Type |
2WD Wheeled Type |
Dimensions of Tractor |
Length(With front ballast) |
3835 |
Width |
1620 |
Height(to the exhaust vent) |
2210 |
Tread |
Front Wheel |
1300 or 1200~1500 Adjusted |
Tread |
Rear Wheel |
1300 Fixed or 1200~1500 Adjusted |
Axle Base |
1910 |
Min.Ground Clearance |
410 |
(kg) Structure weight |
1734 |
Ballast weight
(kg) |
Front ballast |
140 |
Rear ballast |
200 |
Rated traction force (kg) |
880 |
Engine |
Model |
4100 |
Type |
Vertical,4-Cylinder,Water Cooled and 4-stroke |
Rated Power(kw) |
36.7 |
Rated speed (r/min) |
2400 |
Fuel |
Diesel |
Tyre |
Front Wheel |
6.00-16 |
Rear Wheel |
12.4-28 / 14.9-24 |
Clutch |
Dual-stage clutch |
Steering |
power steering |
Transmission Type |
8+4 or 8+8 with shuttle gearshift or (8+4)×2 with creeper shift |
Suspension Type |
3-point links |
PTO |
Type and Rev |
Semi-independent Type 540/1000 |
Spline Size |
F35 Rectangle Spline with 6 teeth |
