Model |
SL404 |
Type |
4WD Wheeled Type |
Dimensions of Tractor(mm) |
Length (to front ballast) |
3835 |
Width |
1620 |
Height (to the exhaust vent) |
2220 |
Tread |
Front Wheel |
1280 |
Tread |
Rear Wheel |
1300 Fixed or 1200~1500 Adjusted |
Axle Base |
2030 |
Min.Ground Clearance |
325 |
Structure weight (kg) |
1665 |
Ballast weight
(kg) |
Front ballast |
140 |
Rear ballast |
200 |
Rated traction force (kg) |
1100 |
Engine |
Model |
3105 / 490 |
Type |
Vertical,Water Cooled and 4-stroke |
Rated Power(kw) |
29.4 |
Rated speed (r/min) |
2400 |
Fuel |
Diesel |
Tyre |
Front Wheel |
8.3-20 |
Rear Wheel |
12.4-28 / 14.9-24 |
Clutch |
Dual-stage clutch |
Steering |
power steering |
Transmission Type |
8+4 or 8+8 with shuttle gearshift or (8+4)×2 with creeper shift |
Suspension Type |
3-point links |
PTO |
Type and Rev |
Semi-independent Type 540/1000 |
Spline Size |
F35 Rectangle Spline with 6 teeth |
